Meljac Wall Switch Wiring Guides



Meljac Wall Switches can be used with Insteon Micro Modules and Insteon DIN Rail Modules. Use the wiring guides in this article to properly wire your switch and module.

The wiring diagrams in this article detail installation for Micro Modules with Meljac switches that include an indicator LED. The wiring procedure is identical for DIN Rail Modules; DIN Rail Modules cannot be installed in the same junction box and must utilize home run wiring.



Toggle Switch Wiring

Place Micro Module in latching mode to ensure functionality with your Meljac toggle switch.

  1. Press and hold the set button until Micro Module beeps
  2. Press and hold the set button a second time
  3. Press and hold the set button a third time
  4. Tap the set button six times
  5. Press and hold the set button until Micro Module double-beeps.


Single-Momentary Wiring

Place Micro Module in single-momentary mode to ensure functionality with your Meljac push-button switch.

  1. Press and hold the set button until Micro Module beeps
  2. Press and hold the set button a second time
  3. Press and hold the set button a third time
  4. Tap the set button four times
  5. Press and hold the set button until Micro Module double-beeps


Dual-Momentary Wiring

Place Micro Module in dual-momentary mode to ensure functionality with your Meljac dual-push button switch.

  1. Press and hold the set button until Micro Module beeps
  2. Press and hold the set button a second time
  3. Press and hold the set button a third time
  4. Tap the set button five times
  5. Press and hold the set button until Micro Module double-beeps
